17686-BLADE TYPE MINI FUSE TAP 50pk

“Tapping” fuse blocks equipped with mini fuses are No Problem!

Now there’s a quick, easy alternative to direct wiring for tapping the “hot side” of mini fuse style fuse blocks. The blade type fuse tap is made of .016" thick sturdy brass with a .187" (3/16") wide tab. It is engineered for quick connect and disconnect of accessories.

Installation can be completed in three steps.

1. Locate “hot side” of circuit in the fuse block with a test  probe. Slide the tap onto the corresponding “hot side” blade of the fuse.
2. Insert the fuse into the fuseblock
3. Crimp one end of an in-line fuse holder (with the fuse installed) to the appropriate Auveco female connector 8781 (16-14 ga.) or 12159 (22-18 ga.). Attach the other fuse holder lead to the accessory wire. Slide the female connector onto the protruding tab of the tap.
